Bosch eBike Flow Integration for Home Assistant

Initially forked from Phil Barker

Monitor and control your Bosch eBike directly from Home Assistant! Track battery level, charging status, range estimates, and create smart charging automations.

• Total Distance/Odometer – Total distance cycled
  (the integration will also import history data from your previous activities)
• Charge Cycles – Number of full charge cycles completed
• Lifetime Energy – Total energy delivered over the bike's lifetime
• Motor Hours – Total powered-on time of the drive unit
• Battery Capacity – Total battery capacity
• BASIC Reachable Range – Estimated range per riding mode
• Last Ride – The distance of your latest activity. All additional data (for the last activity) are available via the sensor attributes (see Where to find attributes in HA section):
  • title
  • start time
  • end time
  • timezone of activity
  • activity type (if set)
  • duration (without stops) [in seconds]
  • avg/max speed [in km/h]
  • avg/max cadence
  • avg/max rider power [in watts]
  • avg/max heart rate
  • elevation gain/loss [in meter]
  • calories burnt
  • total driver consumption percentage
  • total battery consumption percentage
  • rider energy share
  • co2 emissions grams
  • co2 emissions car equivalent Grams
  • trick statistics object
  • brake events object
  • assist mode details object
• Location – Last known position of the bike as a device_tracker entity
  This data is based on the polyline from the last ride activity – so don't expect very high accuracy!
• Component Details – Serial numbers and product info
• Software Versions – Track firmware versions of all components

• Battery Level – Real-time battery percentage (SOC))
• Battery Remaining Energy – Available energy in Watt-hours
• Battery Charging – Active charging status
• Live Reachable Range – Estimated range per riding mode (when the bike is online)
• Location – Last known GPS position of the bike as a device_tracker entity
  (requires a ConnectModule registered for the eBike Alarm feature; the position updates when the ConnectModule reports to the Bosch cloud and is polled every 15 minutes)

• Cloud-based polling every 5 minutes
• OAuth2 authentication with Bosch eBike Flow
• Multi-bike support (if you have multiple eBikes)

• Real-time updates while charging

• 📱 Bosch eBike Flow app installed and working
• 🏠 Home Assistant 2025.1.0 or newer
• 🌐 Internet connection for cloud API access

A compatible Bosch Systems [Gen 4 (or higher) Only] eBike. This integration ONLY works with Generation 4 (or higher) of the Bosch eBike Systems that are using the Bosch Flow-MobileApp. Compatible systems are:

• ✅ Performance Line CX Gen 4 (or higher)
• ✅ Performance Line Gen 4 (or higher)
• ✅ Cargo Line Gen 4 (or higher)
• ✅ Any Gen 4 (or higher) system with or without ConnectModule installed

Not Compatible:

• ❌ Gen 3 and older Bosch systems (use Bosch eBike Connect app)
• ❌ Non-Bosch eBike systems

When you want to make use of the optional extended battery sensor data (like SOC), then there are additional requirements:

• 🔌 Bosch ConnectModule - Required hardware that connects your bike to the cloud
  • Cost: ~€100-150 (depending on region)
  • NOT included with most bikes by default
  • Must be purchased separately and installed on your bike
  • Available from Bosch dealers or online retailers

• 💳 Bosch eBike Flow+ Subscription
  • Cost: ~€30-50/year (varies by region)
  • Required for cloud connectivity and remote features
  • Subscribe through the Bosch eBike Flow app

Even if it's optional, it's highly recommended to install HACS (Home Assistant Community Store) to install this integration.

1. Install Integration:
   • Search for "Bosch eBike Flow" in HACS – Important there is already another HACS Bosch eBike Flow integration — Please make sure to select the 'correct' one Bosch eBike Flow (works also without ConnectModule) with the description "Bosch eBike Flow Integration for Home Assistant – support for Bosch eBikes [Generation 4 (or higher)], no ConnectModule required"
   • Click "Download"
   • Restart Home Assistant

2. Configure:
   • Go to Settings → Devices & Services
   • Click "+ ADD INTEGRATION"
   • Search for "Bosch eBike Flow"
   • Follow the OAuth login flow with your Bosch eBike Flow credentials as it's described in the Configuration - OAuth Setup Section

1. Copy the custom_components/bosch_ebike folder to your Home Assistant's custom_components directory
2. Restart Home Assistant
3. Add the integration via Settings → Devices & Services

The integration uses OAuth2 for secure authentication:

1. Click "Add Integration" and select "Bosch eBike Flow"
2. Copy the authorization URL (or click on it directly – but make sure to open it in a new browser tab)
3. Paste it in a new browser tab on your computer
4. Now enable the browser developer tools (F12) for the new tab/browser window. This must be done before you are entering your login credentials.
5. Log in with your Bosch eBike Flow app credentials.
   Please note, that the login screen from Bosch will not complete – you will not be forwarded to a different page after you entered the password and pressed enter. Basically, you are stuck there by purpose, since you now must manually capture the generated authorization code (generated by the Bosch backend). So after you entered your password, the next step is:
6. Find in the 'network'-tab of the browser developer tools the final authorization request (that is failing by purpose).


   • In the network-tab you will find a line (in red) like (example):

     oauth2redirect?state=akY...&code=dd6...5f8

     This is the request you are looking for, right-click on this line and select from the menu (submenu) Copy URL.


   • The full URL you are copying should look like this (example):
     onebikeapp-ios://com.bosch.ebike.onebikeapp/oauth2redirect?state=akY...&code=dd6...5f8


7. Paste the complete copied URL (including the code) back into the Home Assistant setup dialog.
8. Select which bike to monitor (if you have multiple)

📖 Detailed Step-by-Step Authentication Guide - Includes screenshots and troubleshooting!

Right now - nothing...

If you have multiple eBikes registered in the Bosch eBike Flow app:

• Add the integration once for each bike
• Each bike will appear as a separate device in Home Assistant

The ConnectModule updates the Bosch Cloud API when:

• ✅ Bike is charging (plugged in)
• ✅ Bike is powered on
• ✅ Alarm is triggered by motion

When the bike is unplugged, powered off, and stationary, the ConnectModule goes into low-power mode and stops sending updates to the Bosch backend (and therefore also this integration will not receive any updated data).

• 📊 While charging: Sensors update every 5 minutes with current data
• 🔋 Perfect for: Monitoring charge sessions and creating smart charging automations
• ⚠️ Limited when: Bike is stored unplugged and powered off

For detailed sensor reliability information, see SENSOR_RELIABILITY.md.

Preserve battery health by stopping the charge at 80%:

automation:
  - alias: "eBike: Stop charging at 80%"
    description: "Turn off smart plug when bike reaches 80% to preserve battery"
    trigger:
      - platform: numeric_state
        entity_id: sensor.bfe_[your_frame]_battery_level
      above: 80
    condition:
      - condition: state
        entity_id: binary_sensor.bfe_[your_frame]_battery_charging
      state: "on"
    action:
      - service: switch.turn_off
        target:
          entity_id: switch.bike_charger_plug
      - service: notify.mobile_app
        data:
          title: "🔋 eBike Charging Paused"
          message: "Battery at {{ states('sensor.bfe_[your_frame]_battery_level') }}% - charging stopped to preserve battery health"

Get notified when your bike is fully charged:

automation:
  - alias: "eBike: Notify when fully charged"
    trigger:
      - platform: numeric_state
        entity_id: sensor.bfe_[your_frame]_battery_level
        above: 99
      - platform: state
        entity_id: binary_sensor.bfe_[your_frame]_battery_charging
        to: "off"
        for:
          minutes: 1
    condition:
      - condition: numeric_state
        entity_id: sensor.bfe_[your_frame]_battery_level
        above: 95
    action:
      - service: notify.mobile_app
        data:
          title: "🚴‍♂️ eBike Ready!"
          message: "Your bike is {{ states('sensor.bfe_[your_frame]_battery_level') }}% charged and ready to ride!"

type: entities
title: eBike Status
entities:
  - entity: sensor.bfe_[your_frame]_battery_level
    name: Battery Level
  - entity: sensor.bfe_[your_frame]_battery_remaining_energy
    name: Energy Remaining
  - entity: binary_sensor.bfe_[your_frame]_battery_charging
    name: Charging
  - entity: sensor.bfe_[your_frame]_total_distance
    name: Total Distance
  - entity: sensor.bfe_[your_frame]_charge_cycles
    name: Charge Cycles

1. Check Home Assistant logs for errors
2. Ensure you're running HA 2024.1.0 or newer
3. Try restarting Home Assistant after installation

1. Make sure you're using your Bosch eBike Flow app credentials
2. Check that your bike is registered in the Bosch eBike Flow app
3. Ensure your ConnectModule is paired and online

1. Check that your bike's ConnectModule is paired with the Flow app
2. Power on your bike or plug it in to trigger an update
3. Wait up to 5 minutes for the next polling cycle

The ConnectModule only sends updates when:

• Bike is charging
• Bike is powered on
• Alarm is triggered

This is normal behavior. The sensors will update once you power on or plug in your bike.

A common pitfall is that the attributes (like the Last Ride (distance) Entity) are not obviously visible in the sensor entity itself. So how to find them in HA (2026):

1. Find the eBike sensor entity (e.g., sensor.bfe_[your-bike-id]_last_ride_distance)
2. Click on the entity to open its details
3. Click on the dots beside the gear icon and then select Details

When you want to access values of the attributes (e.g., in automations), then you can do this via the state_attr template functionality. E.g. {{ state_attr("sensor.bfe_[your-bike-id]_last_ride_distance", "elevationGain") | default('0') }} to get the value of the elevationGain attribute from the last_ride_sensor (please note that all attributes start with lower case!).

You can find more details about the individual sensors when accessing your HA via http://[your-ha-ip-here]/developer-tools/state and then selecting the individual sensor from the dropdown list, then you can see all the attributes of the sensor.

Based on these attributes, you can create your own template sensors or automations in Home Assistant.

Additional sensors are disabled by default but can be enabled:

1. Go to Settings → Devices & Services
2. Find your eBike device
3. Click the device
4. Enable desired sensors (software versions, serial numbers, etc.)

Enable debug logging in configuration.yaml:

logger:
  default: warning
  logs:
    custom_components.bosch_ebike: debug

• 🐛 Report Bugs: GitHub Issues
• 💬 Discussions: GitHub Discussions

If you like this integration and want to support the development, please consider supporting me on:

Your support helps maintain and improve this integration. Thank you! ☕

This is an unofficial integration and is not affiliated with, endorsed by, or supported by Bosch eBike Systems.

Use at your own risk. The author is not responsible for any damage to your bike, battery, or Home Assistant system.

• Thanks to Phil-Barker for developing the origin integration.

• Thanks to the Home Assistant community
• Built with the Home Assistant integration framework
• Bosch eBike Flow API (reverse engineered)

Enjoying this integration? ⭐ Star the repo and share with other eBike enthusiasts!
