#GUnit

Towards Painless Testing with GoogleTest and GoogleMock...

#Testing

"If you liked it then you should have put a test on it", Beyonce rule

#TDD (Test Driven Development)

"If you want to like it then you should have put a test on it FIRST", Beyonce TDD rule

Red-Green-Refactor requires a quick feedback loop (productivity)
Goal -> 10 minutes per test case
The longer the feedback loop is the more shortcuts will be taken
- Add a new interface or extend an existing one and break [S]OLID?
- Refactor/extract an interface or keep it as it is and don't fix [S]OLID?

#GoogleTest

(+) Widely used
(+) Stable
(+) Powerful
(+) Comes with GoogleMock
(+) Well documented
(-) Macro based
(-) Slow to compile

#GoogleMock

(+) Widely used
(+) Stable
(+) Powerful
(+) Well documented

(-) Hand written mocks

Who likes writing and maintaining these?

class MockInterface : public interface {
public:
  MOCK_CONST_METHOD1(get, bool());
  MOCK_METHOD1(set, void(bool));
};

(-) Macro based
(-) Slow to compile

#ShowCase/Motivation (Towards Painless Testing)

###Example

class interface1 {                          class interface2 {
 public:                                     public:
  virtual ~interface1() = default;             virtual void f2_1() = 0;
  virtual bool f1(int) const = 0;              virtual void f2_2() = 0;
};                                             virtual void f2_3() = 0;
class interface3 {                             virtual void f2_4() = 0;
 public:                                       virtual ~interface2() noexcept {}
  virtual void f3(int, int, int) = 0;        };
  virtual ~interface3() noexcept = default;
};

class example {
 public:
  example(const interface1& i1, interface2& i2, interface3& i3);

  void test() {
    if (i1.f1(42)) {
      i2.f2_1();
    } else {
      i2.f2_2();
    }
    i3.f3(0, 1, 2);
  }

 private:
  const interface1& i1;
  interface2& i2;
  interface3& i3;
};

###Test

GoogleTest/GoogleMock                           | GoogleTest/GoogleMock + GUnit
------------------------------------------------+---------------------------------------------
#include <gmock/gmock.h>                        | #include <GTest.h>
#include <gtest/gtest.h>                        |
                                                |
class mock_i1 : public i1 {                     | // mock_i1 is NOT NEEDED!
public:                                         |
 MOCK_CONST_METHOD1(f1, bool(int));             |
};                                              |
                                                |
class mock_i2 : public i2 {                     | // mock_i2 is NOT NEEDED!
public:                                         |
 MOCK_METHOD0(f2_1, void());                    |
 MOCK_METHOD0(f2_2, void());                    |
 MOCK_METHOD0(f2_3, void());                    |
 MOCK_METHOD0(f2_4, void());                    |
};                                              |
                                                |
class mock_i1 : public i1 {                     | // mock_i3 is NOT NEEDED!
public:                                         |
 MOCK_METHOD3(f3, void(int, int, int));         |
};                                              |

struct BenchmarkTest : testing::Test {          | struct BenchmarkTest : testing::GTest<example> {
 void SetUp() override {                        |  void SetUp() override {
   sut = std::make_unique<example>(m1, m2, m3); |   std::tie(sut, mocks) = make<SUT, NaggyGMock>();
 }                                              |  }
                                                |
 mock_i1 m1;                                    | // mocks and SUT declaration are NOT NEEDED!
 mock_i2 m2;                                    |
 mock_i3 m3;                                    |
 std::unique_ptr<example> sut;                  |
};                                              | };

TEST_F(BenchmarkTest, ShouldCallF1) {           | TEST_F(BenchmarkTest, ShouldCallF1) {
 using namespace testing;                       |  using namespace testing;
                                                |
 EXPECT_CALL(m1,f1(_)).WillOnce(Return(true));  |  EXPECT_CALL(mock<i1>(),(f1)(_)).WillOnce(Return(true));
 EXPECT_CALL(m2,f2_1()).Times(1);               |  EXPECT_CALL(mock<i2>(),(f2_1)()).Times(1);
 EXPECT_CALL(m3,f3(0, 1, 2)).Times(1);          |  EXPECT_CALL(mock<i3>(),(f3)(0, 1, 2)).Times(1);
                                                |
 sut->test();                                   |  sut->test();
}                                               | }
                                                |
TEST_F(BenchmarkTest, ShouldCallF2) {           | TEST_F(BenchmarkTest, ShouldCallF2) {
 using namespace testing;                       |  using namespace testing;
                                                |
 EXPECT_CALL(m1,f1(_)).WillOnce(Return(false)); |  EXPECT_CALL(mock<i1>(),(f1)(_)).WillOnce(Return(false));
 EXPECT_CALL(m2,f2_2()).Times(1);               |  EXPECT_CALL(mock<i2>(),(f2_2)()).Times(1);
 EXPECT_CALL(m3,f3(0, 1, 2)).Times(1);          |  EXPECT_CALL(mock<i3>(),(f3)(0, 1, 2)).Times(1);
                                                |
 sut->test();                                   |  sut->test();
}                                               | }

Note: GUnit deduces constructor parameters automatically!

#GUnit

Header only library
Based on top of GoogleTest/GoogleMock
- GUnit.GMock - GoogleMock without hand written mocks
- GUnit.GTest - Makes creation of System Under Test (SUT) easier
Requirements
- C++14
- GoogleTest (compatible with all versions)
- Tested compilers
  - Clang-3.6+ / GCC-5+

Quick start

$mkdir build && cd build && cmake ..
$make && ctest

Goals
- Makes TDD feedback loop quicker by...
  - Eliminating hand written mocks
  - Speeding up compilation times
  - Simplifying System Under Test (SUT) creation
How?
- It's not a C++ standard solution (depends on vtable implementation)
  - Itanium C++ ABI (vtable)
  - VTable in GCC
  - Deleting Destructors
  - Devirtualization in C++
  - Member Function Pointers and the Fastest Possible C++ Delegates
  - g++ -fdump-class-hierarchy interface.hpp
- Similar projects (FakeIt, HippoMocks)
Compile time benchmark (Example)

Compiler Number of Mocks GoogleMock/GoogleTest GoogleMock/GoogleTest + GUnit

GCC-6 3 2.6s 2.1s

Clang-3.9 3 2.3s 1.9s

#GUnit.GMock

GoogleMock without writing and maintaining mocks by hand
Supported features
- EXPECT_CALL (requires additional parens for function call)
```
EXPECT_CALL(mock, function()).WillOnce(Return(true)); // GoogleMock
EXPECT_CALL(mock, (function)()).WillOnce(Return(true)); // GUnit.GMock
```
- ON_CALL (requires additional parens for function call)
```
ON_CALL(mock, function()).WillByDefault(Return(true)); // GoogleMock
ON_CALL(mock, (function)()).WillByDefault(Return(true)); // GUnit.GMock
```
- Return/ReturnRef
- WaggyMock/StrictMock/NiceMock
- Compile error when parameters and expectations don't match
- It works together with traditional GoogleMock mocks (See Example)

Synopsis

namespace testing {
  template <class T>
  class GMock {
    static_assert(std::is_abstract<T>::value, "T has to be an abstract type");
    static_assert(std::has_virtual_destructor<T>::value, "T has to have a virtual destructor");

    GMock() = default;
    GMock(GMock &&) = default;
    GMock(const GMock &) = delete;

  public:
    using type = T;

    T&() object();
    const T&() object() const;

    explicit operator T&();
    explicit operator const T&() const;
  };

  template <class T>
  using NaggyGMock = GMock<T>;

  template <class T>
  using StrictGMock = StrictMock<GMock<T>>;

  template <class T>
  using NiceGMock = NiceMock<GMock<T>>;

  /**
   * [Proposal - generic factories]
   *   http://www.open-std.org/jtc1/sc22/wg21/docs/papers/2016/p0338r0.pdf
   *
   * @tparam T type to be created ex. std::unique_ptr<example>
   * @param args arguments (converts GMock for given types T*, T&, shared_ptr, unique_ptr)
   * @return T instance
   */
  template <class T, class... TArgs>
  auto make(TArgs&&... args);
} // testing

namespace std {
  template <class T, class TDeleter>
  std::unique_ptr<T, TDeleter> move(unique_ptr<testing::GMock<T>, TDeleter>& mock) noexcept;

  template <class T, class U>
  std::shared_ptr<U> static_pointer_cast(const std::shared_ptr<testing::GMock<U>>& mock) noexcept;
} // std

#GUnit.GMock - Tutorial by Example

class iconfig {
 public:
  virtual bool is_dumpable() const = 0;
  virtual ~iconfig() = default;
};

class iprinter {
 public:
  virtual ~iprinter() = default;
  virtual void print(const std::string& text) = 0;
};

class example {
 public:
  example(const iconfig& config, const std::shraed_ptr<iprinter>& printer)
    : config(config), printer(printer)
  { }

  void update() {
    if (config.is_dumpable()) {
      printer->print("text");
    }
  }

 private:
  const iconfig& config;
  std::shared_ptr<iprinter> printer;
};

##Test (V1)

TEST(Test, ShouldPrintTextWhenUpdate) {
  using namespace testing;
  GMock<iconfig> mockconfig; // defines and creates a mock
  auto mockprinter = std::make_shared<GMock<iprinter>>(); // defines and creates a mock

  example sut{static_cast<const iconfig&>(mockconfig)
            , std::static_pointer_cast<iprinter>(mockprinter)};

  EXPECT_CALL(mockconfig, (is_dumpable)()).WillOnce(Return(true)); // additional parens
  EXPECT_CALL(*mockprinter, (print)("text")); // additional parens

  sut.update();
}

(+) NO HAND WRITTEN MOCKS
(-) Additional casting of mocks is required
(~) Additional parens with a method call

Can we do better?

##Test (V2) / using make

TEST(Test, ShouldPrintTextWhenUpdate) {
  using namespace testing;
  StrictGMock<iconfig> mockconfig; // strict mock
  auto mockprinter = std::make_shared<StrictGMock<iprinter>>(); // strict mock

  auto sut = make<example>(mockconfig, mockprinter); // automatically converts mocks to interfaces

  EXPECT_CALL(mockconfig, (is_dumpable)()).WillOnce(Return(true));
  EXPECT_CALL(*mockprinter, (print)("text"));

  sut.update();
}

(+) No castings required

Is the make call generic?

##Test (V2.1) / using make and unique_ptr

TEST(Test, ShouldPrintTextWhenUpdate) {
  using namespace testing;
  StrictGMock<iconfig> mockconfig;
  auto mockprinter = std::make_shared<StrictGMock<iprinter>>();

  // create a unique_ptr
  auto sut = make<std::unique_ptr<example>>(mockconfig, mockprinter);

  EXPECT_CALL(mockconfig, (is_dumpable)()).WillOnce(Return(true));
  EXPECT_CALL(*mockprinter, (print)("text"));

  sut->update();
}

#GUnit.GTest

Removes boilerplate mocks declaration
Creates System Under Test (SUT) the same way despite the constructor changes

Synopsis

namespace testing {
  /**
   * [Proposal - generic factories]
   *   http://www.open-std.org/jtc1/sc22/wg21/docs/papers/2016/p0338r0.pdf
   *
   * @tparam T type to be created ex. std::unique_ptr<example>
   * @tparam TMock mock type
   *          NaggyMock  - warning (default)
   *          StrictMock - error
   *          NiceMock   - ignore
   *
   * @tparam TMocks specific mocks different than defaulted by TMock
   *          ex. StrictGMock<interface>
   *
   * @param args arguments (converts GMock for given types T*, T&, shared_ptr, unique_ptr)
   * @return pair{T, mocks}
   */
  template <class T, template <class> class TMock, class... TMocks, class... TArgs>
  auto make(TArgs&&... args);

  template <class T>
  class GTest : public Test {
  public:
    using SUT = std::unique_ptr<T>;

  protected:
    template <class TMock>
    decltype(auto) mock();

    SUT sut;
    mocks_t mocks;
  };
} // testing

##Test (V3 - C++17)

TEST(Test, ShouldPrintTextWhenUpdate) {
  using namespace testing;
  auto [sut, mocks] = make<example, NaggyMock>(); // create NaggyMocks when required

  EXPECT_CALL(mocks.mock<iconfig>(), (is_dumpable)()).WillOnce(Return(true));
  EXPECT_CALL(mocks.mock<iprinter>(), (print)("text"));

  sut.update();
}

(+) Required mocks are created automatically

(+) example constructor might be refactored without changing test cases!

make<example, NaggyMock>() can create...
  example(const std::shared_ptr<iprinter>& printer, const iconfig& config);
  example(const iconfig& config, iprinter& printer);
  example(iconfig* config, iprinter* printer);
  ...

##Test (V3 - C++14)

TEST(Test, ShouldPrintTextWhenUpdate) {
  using namespace testing;
  std::unique_ptr<example> sut;
  mocks_t mocks;
  std::tie(sut, mocks) = make<std::unique_ptr<example>, StrictMock>(); // create StrictMock when required

  EXPECT_CALL(mocks.mock<iconfig>(), (is_dumpable)()).WillOnce(Return(true));
  EXPECT_CALL(mocks.mock<iprinter>(), (print)("text"));

  sut->update();
}

Let's refactor (remove duplicates) from V3 then!

##Test (V4) / using GTest

class Test : public GTest<example> {
public:
  void SetUp() override {
    std::tie(sut, mocks) = testing::make<SUT, NaggyMock>();
  }
};

TEST(Test, ShouldPrintTextWhenUpdate) {
  using namespace testing;
  EXPECT_CALL(mock<iconfig>(), (is_dumpable)()).WillOnce(Return(true));
  EXPECT_CALL(mock<iprinter>(), (print)("text"));

  sut->update();
}

(+) No repetitions with more than 1 test!

[Advanced] Constructors with non-interface parameters and make (Assisted Injection)

  example(iconfig& config, int value, const std::shared_ptr<iprinter>& printer, int data);
                            ^                                                   ^
                            \_____________________       _______________________/
                                                  \     /
  std::tie(sut, mocks) = make<example, StrictMock>(42, 77); // order of the same types is important
                                                            // but it's not imortant for unique types

##[Advanced] Generic Factories

template <class T, class... TArgs>
struct ifactory {
  virtual T create(TArgs...) = 0;
  virtual ~ifactory() = default;
};

using iconfigfactory = ifactory<iconfig, std::string>;

GMock<iconfig> mockconfig;
EXPECT_CALL(mock<iconfigfactory>(), (create)("string")).WillOnce(Return(mockconfig));

(+) No specfic factory mocks for given number of parmaeters
(+) Factory aliases can be used to determine the mock

##Vision for C++20?

SG7: Mocks generation using static reflection (http://www.open-std.org/jtc1/sc22/wg21/docs/papers/2016/p0194r0.pdf)

###Test (V5)

"example"_test_fixture = [] {
  auto [sut, mocks] = make<example, NaggyMock>();

  "should print text when update"_test = [=] {
    using namespace testing;
    EXPECT_CALL(mocks<iconfig>(), (is_dumpable)()).WillOnce(Return(true));
    EXPECT_CALL(mocks<iprinter>(), (print)("text"));
    sut->update();
  };
};

##Limitations

GMock can't mock classes with multiple or virtual inheritance
GMock, by default, can fake interface with up to 128 virtual methods

##FAQ

How to mock overloaded methods?

class interface {
 public:
  virtual void f(int) = 0;
  virtual void f(int) const = 0;
  virtual ~interface() = default;
};

GMock<interface> mock;

EXPECT_CALL(mock, (f, void(int) const)(1));
EXPECT_CALL(mock, (f, void(int))(2));

static_cast<const interface&>(mock).f(1);
mock.object().f(2);

Can GUnit be used with Catch?
- Yes, GUnit isn't tied to GoogleTest, however it's tied to GoogleMock
But virtual function call has performance overhead?
- This statement is not really true anymore with modern compilers as most virtual calls might be inlined

##Acknowledgements

Thanks to Eran Pe'er and Peter Bindels for FakeIt and HippoMocks

##References

Meeting C++ 2016: Mocking C++
Meeting C++ 2016: TDD/BDD and Dependency Injection | Slides
Automatic Mocks Injector
[Boost].DI - Dependency Injection Library

Name		Name	Last commit message	Last commit date
benchmark		benchmark
example		example
include		include
libs		libs
test		test
.clang-format		.clang-format
.gitmodules		.gitmodules
.travis.yml		.travis.yml
CMakeLists.txt		CMakeLists.txt
README.md		README.md

Navigation Menu

Repository navigation

About

Repository files navigation

[Advanced] Constructors with non-interface parameters and make (Assisted Injection)

About

Releases

Packages

Used by

Contributors

Languages

Compiler	Number of Mocks	GoogleMock/GoogleTest	GoogleMock/GoogleTest + GUnit
GCC-6	3	2.6s	2.1s
Clang-3.9	3	2.3s	1.9s

Latest commit

History

Folders and files

Repository files navigation

[Advanced] Constructors with non-interface parameters and make (Assisted Injection)

About

Topics

Resources

Stars

Watchers

Forks

Releases

Packages

Used by

Contributors

Languages
